Daewoo Puma 2000 SY

Daewoo Puma 2000 SY

£47950.00

		http://www.youtube.com/v/OGoToBZW7Dk&hl=en_GB&fs=1&

Year:		2002
Make:		Daewoo
Model:		Puma 2000 SY
Maximum Cutting diameter:		330mm
Driven Tools Max Spindle Speed:		5000rpm
Maximum Turning Length:		510mm
Bar Capacity:		65mm
Y axis Travel:		(100mm) +- 50mm
Turret Positions:		12
Sub Spindle Max Speed:		6000rpm
Swing:		600mm
Rapid Feedrates:		20&24m/Min
Sub Spindle Motor Power:		7.5kW
Machine Weight:		4850kg
Machine Dimensions L x D x H:		3118mm x 1700mm x 2060mm
C axis:		0.001 deg
Control:		Fanuc 18iTB
Configuration:		Twin Spindle With Y Axis
Chuck Size:		210mm
Description:		C axis & Milling, Sub Spindle, Swarf conveyor, Tool setter, Y-Axis, 3 Jaw Chuck, Magazine Barfeed, Collet Chuck, Parts Catcher, Manuals, Tooling, Full Length Magazine Bar Feed, Magazine Barfeed Interface.
